CLW 16000L RHD Water and Foam Rescue Fire Truck For Sale From Manufacturer
- CLW
- Suizhou city, Hubei Province
- 35 working days after received your payment
- 100 units per month
- 51000USD-60000USD
- 30% Payment In Advance, 70% Payment Before Shipping From Factory
1
Basic Parameters of CLW 16Tons RHD Water and Foam Fire Truck
CLW 16Tons RHD Water and Foam Fire Truck
CLW 16Tons RHD Water and Foam Fire Truck
| General | Truck Brand | CLW/DONGFENG |
| Model | CLW5251GXFPM35 | |
| Overall Size | 10190*2550*3730mm | |
| Volume | Water: 14000L, Foam:2000L | |
| G.V.W | 25000kg | |
| Curb Weight | 15250kg | |
| Engine | Model | B210 33 |
| Power | 210HP/155KW | |
| Displacement | 5.9L | |
| Emission Standard | Euro III | |
| Cylinder | 6 | |
| Fuel Type | Diesel | |
| WheelBase | 4350+1300mm | |
| Transmission | Model | FAST |
| Numbers | 8 forward, 1 Revise | |
| Tires | Size | 11.00R20 |
| Number | 10+1 | |
2
Special Function of CLW 16Tons RHD Water and Foam Fire Truck
Fire Pump
Foam Proportion
Fire Gun
Volume | Water: 14000L, Foam:2000L | |
| Material | Water Tank:high quality carbon steel plate | |
| Thickness | Bottom Plate | 4mm |
| Front Cover Plate | 4mm | |
| Rear Cover Plate | 4mm | |
| Side Plate | 3mm | |
| Fire Pump | Model | CB10/60 |
| Flow | 60L/s | |
| Pressure | 1.0Mpa | |
| Water Diversion Time | ≤35s(at suction depth of 7m) | |
| Install Style | Rear Mounted | |
| Foam Proportion | Model | PH64 |
| Pressure | 0.6-1.4Mpa | |
| Flow | 16-64L/S | |
| Ratio Rate | 3%-6%(adjustable) | |
| Type | Manual | |
| Fire Gun | Model | PL48 |
| Pressure | 1.0Mpa | |
| Flow | 48L/s | |
| Range | water:≥60m, Foam:≥55m | |
| Rotation angle | Horizontal 360°, pitch -30°～80 | |
| Operation Style | Manual | |
3
Cabin of CLW 16Tons RHD Water and Foam Fire Truck
Cabin
2+4 Cabin
2+4 Cabin
| Structure | Flat head four-door double-row cab, all-steel frame welded structure |
Seats | Front:2 persons, Rear: 4 Person |
| Equipment | 100W siren, rotary warning light switch, power take-off Control switch and indicator light |
4
Pump Room,Equipment Box
Parts of 16Tons fire truck
Parts of 16Tons Fire Truck
Parts of 16Tons Fire Truck
Material | The frame and skin are made of high-quality steel, and the pump room wall panels, equipment box bottom panels and four wall panels are all made of high-quality steel plates |
Structure | The pump room and equipment box are all steel frame welded structures, and there are aluminum alloy curtain doors on the left and right sides of the equipment box and the left and right rear sides of the pump room. |
5
Electrical System
※There is a long row of warning lights at the front of the cab.
※ There is a 12V, 60W fire scene lighting lamp behind the roof.
※ There are two flashing lights on each side of the vehicle, and a safety sign light is installed below, equipped with front and rear clearance lights, a turn signal on each side, and lighting in the passenger room, equipment box, and pump room, which complies with GB4785 regulations.
※ The power of the alarm is 100W; the alarm, warning light, and flashing light circuits are independent additional circuits, and the control device is installed in the cab.
※ Additional instruments and switches are centrally arranged on the control panel for easy operation. The dashboard is equipped with: 1 vacuum gauge, 1 pressure gauge; 1 fire pump tachometer; 2 liquid level indicators; pump room and equipment box light switches, etc. (the dashboard is located in the pump room).
6
Advantage of CLW 16Tons RHD Water and Foam Fire Truck
CLW 16000L RHD Water and Foam Rescue Fire Truck built on Dongfeng Motor Corporation's specialized fire truck chassis, this right-hand drive vehicle features a 6x4 drive configuration, a 4325+1350 wheelbase, and a 210-horsepower Cummins engine. This model offers high cost-effectiveness, strong parts interchangeability, and low maintenance costs.
Applications
Urban & Industrial Firefighting: Widely used by municipal fire departments and petrochemical plants, combining fire suppression with emergency rescue capabilities.
Special Environments: The 6x4 version is specifically designed for forests and hilly terrain, offering superior maneuverability.
7
Video
Water Tank
Powder Tank
What is your terms of payment?
T/T, 30% as deposit, and 70% before delivery. we’ll show you the phone and video of truck, before you pay the balanceHow about your delivery time?
Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.Do you test all your goods before delivery?
yes of course, we have 100% test before delivery.How do you make our business long-term and good relationship?
We keep good quality and competitive price to ensure our customers benefit; we respect every customer as our friend and we sincerely do business and make friends with them, no matter where they com from.
