DONGFENG 45M Aerial Lift Work Truck With Boom Platform From Manufacturer

The DONGFENG 45M Aerial Lift Work Truck can be selected in 4*2 or 4*4 drive form and is suitable for urban roads or complex terrains. It adopts Dongfeng KR chassis, Cummins B190 engine, seven-section telescopic straight arm, and a maximum operating height of 45 meters. It covers high-difficulty scenarios such as super-high-rise building exterior wall construction and power inspection.

The outriggers of Truck With Boom Platform adopt the front V and rear V-shaped structures, with a larger force-bearing surface and higher stability; they can prevent the vehicle frame from deformation or breakage. The outriggers are individually adjustable, and each outrigger can be adjusted individually according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state. All outriggers are equipped with outrigger warning flashing lights, which are used to indicate the outline of the outriggers during operation and send out light warning signals.

Platform Operation

Aerial Work Truck has one 5-inch LCD screen, real-time display of detection arm length, elevation angle, platform height, working height, etc.

Remote Control Operation

Aerial Work Truck with Standard wireless remote control operation, real-time data display, simple and easy to set, quick and sensitive operation, automatic working range limit, when the working range reaches the specified value, automatically limit the dangerous direction of work. The controller can ignite the engine,

Outriggers

Aerial Work Truck with Front V and rear V-shaped double-section hydraulic outriggers, rear outriggers sinking, low center of gravity, greater stability

Upper arm

18-sided new structure of Aerial Work Truck, synchronous telescopic, polygonal boom structure, enhanced boom strength, external telescopic cylinder with additional protective cover

Winch hook

Aerial Work Truck can install 1 ton winch hook to assist in simple lifting operations.

Mains power interface

It is a tool for Aerial Work Truck. Provide 220V power supply.

Soft leg protection

When the outriggers are not properly supported on the ground, the lifting arm of Aerial Work Truck will limit work in the dangerous direction.

Operation Room

Manual operation with a cab installed to protect workers from wind and rain.
